Name: CPC HRC45FL Linear Guideway Block HRC45FLBV1N CNC Linear Block
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: HRC45FL
Price: 499.10 USD
Availability: InStock

MOQ:	1 pcs
Price:	Negotion
Standard Packaging:	Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Period:	3 working days after received your payment
Payment Method:	T/T or western Union or PayPal
Supply Capacity:	3,000pcs per month

Details Information

Product Description

Detail Information

Place of Origin

Taiwan

Brand Name

CPC

Certification

ISO

Model Number

HRC45FL

Height:

60 Mm

Width:

120 Mm

Length:

171.5 Mm

Type:

Linear Block

Precision Rating:

P0 P6 P5 P4 P2

Highlight:

HRC45GLBV1N Linear Guideway Block

Low Friction Linear Guideway Block

CPC Linear Guideway Block

Product Description

CPC HRC45FL Linear Guideway Block HRC45FLBV1N CNC Linear Block

1. Type: linear guideway block

2. Dimension:

Part number	HRC45GLBV1N
Block heigh	60 mm
Block width	120 mm
Block length	171.50 mm

3. Feature:

(1) Linear guideway block

(2) Taiwan origin

(3) Low noisy,low friction

(4) Quality guarantee

4. Bearing photos:

CPC HRC45FL Linear Guideway Block HRC45FLBV1N CNC Linear Block 0

5.We aslo supply following bearings:

Part number	Componets dimension mm			Block dimension mm												Rail dimension mm							Bolt size	dynamic loading rate	static loading rate	Static torque kgf.m
	H	H₁	N	W	B	B₁	C	L₁	L	K₁	G	M×L	T	H₂	H₃	W_R	H_R	D	h	d	P	E	mm	C(kN)	C₀(kN)	M_R	M_P	M_Y
GHH 15CA	28	4.3	9.5	34	26	4	26	39.4	61.4	10	5.3	M4×5	6	7.95	7.7	15	15	7.5	5.3	4.5	60	20	M4×16	11.38	16.97	0.12	0.10	0.10
GHH 20CA	30	4.6	12	44	32	6	36	50.5	77.5	12.25	12	M5×6	8	6	6	20	17.5	9.5	8.5	6	60	20	M5×16	17.75	27.76	0.27	0.20	0.20
GHH 20HA							50	65.2	92.2	12.6														21.18	35.9	0.35	0.35	0.35
GHH 25CA	40	5.5	12.5	48	35	6.5	35	58	84	15.7	12	M6×8	8	10	9	23	22	11	9	7	60	20	M6×20	26.48	36.49	0.42	0.33	0.33
GHH 25HA							50	78.6	104.6	18.5														32.75	49.44	0.56	0.57	0.57
GHH 30CA	45	6	16	60	40	10	40	70	97.4	20.25	12	M8×10	8.5	9.5	13.8	28	26	14	12	9	80	20	M8×25	38.74	52.19	0.66	0.53	0.53
GHH 30HA							60	93	120.4	21.75														47.27	69.16	0.88	0.92	0.92
GHH 35CA	55	7.5	18	70	50	10	50	80	112.4	20.6	12	M8×12	10.2	16	19.6	34	29	14	12	9	80	20	M8×25	49.52	69.16	1.16	0.81	0.81
GHH 35HA							72	105.8	138.2	22.5														60.21	91.63	1.54	1.40	1.40
GHH 45CA	70	9.5	20.5	86	60	13	60	97	139.4	23	12.9	M10×17	16	18.5	30.5	45	38	20	17	14	105	22.5	M12×35	77.57	102.71	1.98	1.55	1.55
GHH 45HA							80	128.8	171.2	28.9														94.54	136.46	2.63	2.68	2.68
GHH 55CA	80	13	23.5	100	75	12.5	75	117.7	166.7	27.35	12.9	M12×18	17.5	22	29	53	44	23	20	16	120	30	M14×45	114.44	148.33	3.69	2.64	2.64
GHH 55HA							95	155.8	204.8	36.4														139.35	196.2	4.88	4.57	4.57
GHH 65CA	90	15	31.5	126	76	25	70	144.2	200.2	43.1	12.9	M16×20	25	15	15	63	53	26	22	18	150	35	M16×50	163.63	215.33	6.65	4.27	4.27
GHH 65HA							120	203.6	259.6	47.8														208.36	303.13	9.38	7.38	7.38

If you want to buy CPC HRC45FL linear block,just contact us.
