GQZ LMS3 Miniature Straight Linear Ball Bushing 3×7×10mm Precision Micro Linear Motion Bearing

LMS3 is miniature straight-type linear ball bushing.

Common variants:

• LMS3:Open type, no seals
• LMS3UU:Double-sided contact rubber seals
• LMS3F:Stainless steel version

It is matched with Φ3mm linear shaft to realize endless reciprocating linear movement. Circumferentially arranged steel balls keep low friction sliding performance. Sealed variant locks internal grease to achieve long maintenance-free running; open version supports regular re-lubrication. Widely used for miniature automated assemblies, optical testing equipment, medical instruments and compact precision machinery with limited installation space.

Formal quotation will be sent within 24 hours upon your inquiry.

Model

LMS3

Dimensions

d3 mm, D7 mm, L10 mm

Net weight

approx 0.0014 kg

Structure

Straight miniature linear ball bushing

Material

Outer sleeve & steel balls: GCr15 bearing steel; POM retainer

Basic dynamic load Cr

21.2 N

Basic static load C0r

55.8 N

Limiting speed (grease)

12000 rpm

Complete dimension drawings and load data available on request.

1. Ultra-miniature compact dimension, perfect for narrow space mechanical layout
2. Rolling contact structure provides low friction resistance and smooth linear movement
3. Multiple optional configurations: open / sealed / stainless steel type for diverse working conditions
4. Precision machined outer sleeve and ball raceway, stable positioning accuracy
5. Standard industry dimension, fully interchangeable with global mainstream LMS series
6. Customizable: OEM laser marking, low-temperature / high-temperature special grease, P6 precision grade

• Miniature automated assembly lines and small linear sliding mechanisms
• Optical testing instruments, precision office and printing equipment
• Medical automation miniature transmission assemblies
• Semiconductor small conveying and positioning equipment
• Light-load low-speed reciprocating linear motion machinery

25 years professional bearing manufacturer, products exported globally.

Strict dimensional sorting for steel balls to guarantee smooth sliding performance.

Stable forming process for plastic retainer, resistant to deformation.

24-hour technical support for variant selection and shaft matching suggestion.

Ample stock for machinery distributors.

Precise dimensions and stable service performance.

GCr15 raw material quenching & tempering hardness inspection

Precision superfinishing for outer sleeve inner raceway

Steel ball surface roughness and dimension inspection

Whole set sliding smoothness test

If you need LMS3 linear ball bushings:

Send inquiry to obtain below supports:

• Quick quotation within 24 hours
• LMS3UU sealed variant consultation
• Stainless steel LMS3F solution
• Competitive factory direct price

Contact our sales team for full datasheets and formal offer.
