KWVE20B-V1-G3 Four Row Standard Carriage KWVE20BV0G2 Linear Guide Block 20x63x30mm

1. Product Overview

The KWVE20B-V1-G3 is Schaeffler INA standard KWVE series flanged four-row recirculating ball linear guide block, matching 20mm width linear guide rail. It adopts O-type 45° four-ball contact structure to realize equal load capacity in four directions, equipped with V1 slight preload to eliminate clearance and improve running rigidity, G3 high precision grade guarantees ultra-low positioning tolerance. Double composite dustproof seals block metal chips, cutting fluid and dust, built-in M5 grease nipple supports convenient online relubrication without disassembly. Flange top-through mounting holes realize flexible installation on horizontal, vertical and inverted equipment layouts, widely used for precision CNC machine tools, electronic automation equipment, testing jigs, packaging machinery and high-precision linear transmission platforms requiring stable high accuracy.

Get a quote within 24 hours for your project

2. Technical Specifications

Complete dimensional drawings, precision tolerance tables and life calculation data are available upon customer request.

3. Key Advantages

• G3 high precision tolerance standard, excellent straightness and repeated positioning accuracy, perfect for precision machining and detection equipment
• V1 slight preload eliminates internal play, improves motion rigidity, avoids vibration and jump under medium-speed reciprocating movement
• O-type four-way equal load design, consistent rigidity under radial, reverse radial and lateral composite loads, multi-angle installation without performance loss
• Flange wide body structure increases mounting contact area, stable fixation on thin plate equipment without additional support blocks
• Double-layer composite sealing system isolates workshop coolant, metal debris and dust, pre-filled long-life lithium grease to extend maintenance cycle
• Customizable options: V2 medium preload, G4 ultra-precision grade, thickened UU dust seals, stainless steel anti-corrosion version, OEM laser marking, arbitrary rail fixed cutting length

Effectively improve equipment processing precision and reduce downtime for linear system maintenance

4. Applications

This KWVE20B-V1-G3 precision flanged linear guide block is widely matched for the following high-precision industrial equipment:

• Small CNC engraving machines, milling machines and lathe feed axis positioning assemblies
• 3C electronic automatic assembly equipment, handling gantry and precision testing jigs
• Medical automation testing equipment, laboratory precision sliding platforms and inspection fixtures
• Printing, food packaging machinery and textile high-speed tension moving mechanisms
• Woodworking precision cutting equipment and injection molding auxiliary linear sliding units
• Aftermarket replacement spare parts for imported INA KWVE series 20mm precision linear guide systems

Ideal high-precision slight preload linear slider solution for automation and precision machining production lines

5. Why Choose GQZ Bearing

• 25 years of professional KWVE series INA interchangeable linear guide block manufacturing experience
• Products fully dimensionally interchangeable with original KWVE20 series, compatible with all standard 20mm width linear rails
• Complete OEM & ODM service covering preload adjustment, precision grade selection, rail customized cutting and anti-rust surface passivation
• Full-process strict inspection: steel material hardness, raceway ultra-precision grinding, sealing tightness, preload uniformity and dynamic fatigue load testing before delivery
• Professional linear motion engineering team provides slider-rail matching, installation guidance and precision selection support within 24 hours
• Stable large-scale mass production lines with preferential bulk wholesale price for long-term automation equipment manufacturers

We focus on consistent sliding smoothness, stable precision retention and long service life, building long-term win-win cooperation with global industrial buyers

6. Quality Control

• Raw material chemical composition and surface hardness inspection of GCr15 chrome bearing steel
• Precision mirror grinding processing for four arc raceways of slider and rolling surface of linear guide rail
• Constant temperature heat treatment process to stabilize internal metal stress, enhance wear resistance and contact fatigue life
• Comprehensive performance testing: four-direction load uniformity, V1 preload clearance control, G3 precision tolerance detection, dustproof sealing durability and repeated positioning accuracy
• Final dimensional tolerance, surface finish, marking and sealing assembly re-inspection before vacuum anti-rust packaging shipment

Every batch of sliders passes full sampling cycle reciprocating test to guarantee stable long-term high-precision operation

7. Get a Quote Now

If you need high-quality KWVE20B-V1-G3 G3 precision V1 slight preload flanged linear guide blocks for CNC and electronic automation equipment, send your inquiry to us directly.

You will receive full professional supporting services after submitting inquiry:

• Fast official factory quotation reply within 24 hours
• One-on-one preload grade, precision class and rail length matching technical support by linear motion engineers
• Customized solution suggestions including ultra-precision G4 grade, thickened dust seals and stainless steel anti-rust sliders
• Competitive direct factory bulk wholesale price for separate single slider and complete rail-set orders

Send your required quantity, preload & precision demand and equipment working environment to obtain detailed formal offer
