| Brand Name: | GQZ /OEM |
| Model Number: | 7312B |
| MOQ: | 1 PCS |
| Price: | USD 1-5 |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T |
![]()
*Need a quick quote? Just send us your bearing model & quantity — we’ll get back to you fast.
| Item | Specification |
|---|---|
| Bearing Model | 7312B |
| Bearing Type | Angular Contact Ball Bearing |
| Bore(d) | 60 mm |
| Outer Diameter(D) | 130 mm |
| Width(B) | 31 mm |
| Contact Angle | 40° |
| Basic Dynamic Load(Cr) | 90000 N |
| Basic Static Load(C0r) | 65500 N |
| Limiting Speed Grease | 4300 r/min |
| Limiting Speed Oil | 5600 r/min |
| Weight | 1.78 kg |
| Seal Type | Open Unsealed |
| Cage Material | Steel Cage |
| Material | GCr15 Bearing Steel |
| Tolerance Class | P0 |
| Min Shaft Fillet(r) | 2.1 mm |
*Ready stock. Short lead time. Fast delivery.Send us your bearing list and let’s get started!
![]()
![]()
![]()
![]()
![]()
![]()
Q1: What does B stand for in 7312B?
A1: B means 40° contact angle for higher axial load capacity.
Q2: Can single 7312B bear bidirectional axial load?
A2: No, it only supports one‑direction axial load, use paired mounting for two‑way thrust.
Q3: Is 7312B pre‑lubricated?
A3: Open type without grease filling, manual lubrication required.
Q4: Can 7312B work at high speed?
A4: Yes, it fits medium‑high speed scenarios with proper lubrication.
