Angular Contact Ball Bearing
Created with Pixso. 7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

Brand Name: GQZ /OEM
Model Number: 7312B
MOQ: 1 PCS
Price: USD 1-5
Delivery Time: 3-5 working days
Payment Terms: T/T
Detail Information
Place of Origin:
China
Certification:
ISO9001:2015
Width(B):
31mm
Bearing Model:
7312B
Number Of Row:
Single Row
Inner Diameter(d):
60mm
Material:
GCr15 Chrome Bearing Steel
Outer Diameter(D):
130mm
Seal Type:
OPEN
Packaging Details:
in individual packing box
Supply Ability:
100000 Sets per month
Highlight:

7312B angular contact ball bearing 60x130x31mm

,

single row angular contact bearing for machinery

,

60x130x31mm angular contact ball bearing

Product Description
7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

Product Overview
  • 7312B is single row open‑type angular contact ball bearing with 40‑degree contact angle. It bears combined radial and one‑direction axial loads, suitable for medium‑high speed operating conditions. Made of GCr15 bearing steel for stable mechanical performance.

*Need a quick quote? Just send us your bearing model & quantity — we’ll get back to you fast.

Key Specifiions
Item Specification
Bearing Model 7312B
Bearing Type Angular Contact Ball Bearing
Bore(d) 60 mm
Outer Diameter(D) 130 mm
Width(B) 31 mm
Contact Angle 40°
Basic Dynamic Load(Cr) 90000 N
Basic Static Load(C0r) 65500 N
Limiting Speed Grease 4300 r/min
Limiting Speed Oil 5600 r/min
Weight 1.78 kg
Seal Type Open Unsealed
Cage Material Steel Cage
Material GCr15 Bearing Steel
Tolerance Class P0
Min Shaft Fillet(r) 2.1 mm
Main Features
  • 40 degree large contact angle provides high one‑direction axial load capacity
  • Supports combined radial and axial composite loads
  • Open structure allows flexible lubrication selection
  • Steel cage ensures stable high‑speed rotation
  • High hardness GCr15 material delivers good wear resistance
  • Standard P0 precision for general industrial applications
Typical Appliions
  • Gearboxes
  • Machine tool spindles
  • Electric motors
  • Pumps and compressors
  • General engineering machinery

*Ready stock. Short lead time. Fast delivery.Send us your bearing list and let’s get started!

Why Choose GQZ Bearing
  • 30 years professional bearing industry experience
  • ISO certified strict quality inspection
  • Flexible OEM & private label customization
  • 3-5 days fast delivery for stocked bearings
  • Full bearing series, universal interchangeable size
  • Factory direct price & reliable after-sales service

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

7312B Single Row Angular Contact Ball Bearing 60x130x31mm For Machinery Equipment

FAQ

Q1: What does B stand for in 7312B?
A1: B means 40° contact angle for higher axial load capacity.

Q2: Can single 7312B bear bidirectional axial load?
A2: No, it only supports one‑direction axial load, use paired mounting for two‑way thrust.

Q3: Is 7312B pre‑lubricated?
A3: Open type without grease filling, manual lubrication required.

Q4: Can 7312B work at high speed?
A4: Yes, it fits medium‑high speed scenarios with proper lubrication.
