7214 BECBJ Angular Contact Ball Bearing 125MM SKF Roller Bearings

1
MOQ
1 USD
Price
7214 BECBJ Angular Contact Ball Bearing 125MM SKF Roller Bearings
Features Gallery Product Description Request A Quote
Features
Specifications
Bearing Type: Angular Contact Bearing
ID: 24 MM
Rolling Body: Ball Bearing
Lubrication: Oil
Brand: SKF / GQZ / AAA
OD: 125MM
High Light:

Angular Contact Bearing

,

Steel Cage Bearing

Basic Infomation
Brand Name: SKF / GQZ / AAA
Certification: ISO 9001
Model Number: 7214 BECBJ
Payment & Shipping Terms
Packaging Details: single packing + standard export packing
Payment Terms: T/T, Western Union
Supply Ability: 1000 pcs / month
Product Description



7214 BECBJ Angular Contact Ball Bearing 125MM SKF Roller Bearings



1. Angular  Contact  Bearing  Specification :



Bearing type  Angular Contact Bearing
Bearing Model 7214 BECBJ
Brand SKF / GQZ / AAA
Size (mm) 70*125*24
Weight (kg) 1.12  KG
Stock  Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy



2.Types of bearings:



Angular contact ball bearings are: the type 7000 c (∝ = 15 °), type 7000 ac (∝ = 25 °) and 7000 b (∝ = 40 °) several types.This kind of lock on the outer ring of bearing, general inside and outside the circle cannot be separated, can bear radial and axial load and axial load in one direction.Carry axial load capacity is determined by contact Angle, the larger the contact Angle, is the ability to carry axial load.This kind of bearing can limit shaft or shell axial displacement in one direction.
Contact ball bearing limit rotational speed is higher, can bear radial load and axial load at the same time, also can withstand pure axial load, its axial load capacity is determined by contact Angle, and with the contact Angle increases.



3 . Structure types :



a=15 °7000C

a=25 °7000AC

a=40 °7000B

1) Single row angular contact ball bearing

2) Double row angular contact ball bearing

3) Four-point angular contact ball bearing





4 . Competitive Advantage:


· Competitive Price
· Big Production Ability
· Fast Delivery
· Excellent Sale and After-sale Service
· OEM Available



5. Main application .


Single row angular contact ball bearings, machine tool spindle, high frequency motor, gas turbine, centrifugal separator, small car front wheel, differential pinion shaft, booster pump, drilling platform, food machinery, dividing head, filling machine, low noise type cooling tower, electrical equipment, coating equipment, machine tool trough plate, arc welding machine
Double row angular contact ball bearing, oil pump, roots blower, air compressor, all kinds of transmission, fuel injection pump, printing machinery, planetary reducer, extraction equipment, cycloid reducer, food packaging machinery, electric welding machine, electric, square box, gravity type spray gun, wire stripping machine, axle shaft equipment, chemical machinery, testing analysis



6 . We have enough stock , following is our products in stock .


Principal dimensions Basic load ratings Reference speed Limiting speed Model no.
dynamic static
d D B C C0
mm kN   r/min
65 140 33 116 86,5 6300 6300 7313 BECBP *
65 140 33 116 86,5 6300 6300 7313 BEGAP *
65 140 33 116 86,5 6300 6300 7313 BEGBP *
65 140 33 116 86,5 6300 6300 7313 BECBPH *
65 140 33 116 86,5 6300 6300 7313 BECBM *
65 140 33 116 86,5 6300 6300 7313 BECCM *
65 140 33 116 86,5 6300 6300 7313 BEGAM *
65 140 33 116 86,5 6300 6300 7313 BEGBM *
65 160 37 130 96,5 5000 5300 7413 BCBM
65 160 37 130 96,5 5000 5300 7413 BGAM
65 160 37 130 96,5 5000 5300 7413 BGBM
70 125 24 67,6 56 6000 6000 7214 BEP
70 125 24 71,5 60 6000 6000 7214 BECBJ
70 125 24 71,5 60 6000 6000 7214 BECBY
70 125 24 72 60 6300 6300 7214 BECBP *
70 125 24 75 64 6300 6300 7214 BEGAP *
70 125 24 72 60 6300 6300 7214 BECBM *
70 125 24 72 60 6300 6300 7214 BEGAM *
70 150 35 119 90 5300 5300 7314 BEP
70 150 35 119 90 5300 5300 7314 BECBJ
70 150 35 119 90 5300 5300 7314 BEGAJ
70 150 35 119 90 5300 5300 7314 BECBY
70 150 35 119 90 5300 5300 7314 BEGAY
70 150 35 119 90 5300 5300 7314 BEGBY
70 150 35 119 90 5300 5300 7314 BEGAF
70 150 35 127 98 5600 5600 7314 BECBP *
70 150 35 127 98 5600 5600 7314 BECAP *
70 150 35 127 98 5600 5600 7314 BEGAP *
70 150 35 127 98 5600 5600 7314 BECBPH *
70 150 35 127 98 5600 5600 7314 BECBM *
70 150 35 127 98 5600 5600 7314 BEGAM *
70 180 42 159 127 4500 4800 7414 BCBM
70 180 42 159 127 4500 4800 7414 BGAM
75 130 25 70,2 60 5600 5600 7215 BEP
75 130 25 73,5 65,5 6300 6300 7215 BECBP
75 130 25 73,5 65,5 6300 6300 7215 BECBM
75 130 25 72,8 64 5600 5600 7215 BECBJ
75 130 25 72,8 64 5600 5600 7215 BECBY
75 130 25 72,8 64 5600 5600 7215 BEGAY
75 160 37 125 98 5000 5000 7315 BEP
75 160 37 133 106 5000 5000 7315 BECBJ
75 160 37 133 106 5000 5000 7315 BECBY
75 160 37 132 104 5300 5300 7315 BECBP *
75 160 37 132 104 5300 5300 7315 BEGAP *
75 160 37 132 104 5300 5300 7315 BECBPH *
75 160 37 132 104 5300 5300 7315 BECBM *
75 160 37 132 104 5300 5300 7315 BEGAM *
75 190 45 168 140 4300 4500 7415 BM
75 190 45 168 140 4300 4500 7415 BCBM
75 190 45 168 140 4300 4500 7415 BGAM
75 190 45 168 140 4300 4500 7415 BGBM
80 140 26 80,6 69,5 5300 5300 7216 BEP
80 140 26 83,2 73,5 5300 5300 7216 BECBJ
80 140 26 83,2 73,5 5300 5300 7216 BECBY
80 140 26 80,6 69,5 5300 5300 7216 BEGAF
80 140 26 85 75 5600 5600 7216 BECBP *
