Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2

I'm Online Chat Now
Certification
China Wuxi Guangqiang Bearing Trade Co.,Ltd certification
Received bearings. Very impressed with the quality. Warm and thoughtful service,fast shipment.I will keep doing business with your trustworthy company

—— John Grafton

More than 3 years business cooperation with your company has brought us a lots of benefits.We attain many local customers gratitude and supports.Thank

—— Mohammad EL ASSWAD

We have tested the bearing 23082 and I am so satisfied with the bearing quality.Good package and best price have given a big favor in our business.

—— Minwoo, Kwon

Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2

Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2
Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2 Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2

Large Image :  Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2 Get Best Price

Product Details:
Brand Name: SKF / GQZ / AAA
Certification: ISO 9001
Model Number: 7415 BCBM
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 1 USD
Packaging Details: single packing + standard export packing
Payment Terms: T/T, Western Union
Supply Ability: 1000 pcs / month
Detailed Product Description
Bearing Type: Angular Contact Bearing Cage: Brass / Steel
Rolling Body: Ball Bearing Number Of Row: Double
Load Direction: Radial Bearing Material: Bearing Steel
High Light:

Angular Contact Bearing

,

Steel Cage Bearing

Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2



1. Angular  Contact  Bearing  Specification :



Bearing type  Angular Contact Bearing
Bearing Model 7415 BCBM
Brand SKF  / GQZ / AAA
Size (mm) 75*190*45
Weight (kg) 5.9  KG
Stock  Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy



2. Desprition :



High speed precision angular contact ball bearing, mainly used for high speed rotating load lighter, bearings and high precision, high speed, low temperature rise, low vibration and service life.Often for high speed motorized spindle bearing parts installed in pairs, is the key to the high-speed motorized spindle surface grinding machine fittings.
The main technical indicators:
1. The bearing precision index: more than GB / 307.1 94 P4 level precision
2. High speed performance indicators: dmN value 1.3 ~ 1.3 x 106 / min
3. The service life (on average) : > 1500 h
High speed precision angular contact ball bearing service life had a lot to do with the installation, the following should be paid attention to
1. The bearing installation should be clean, clean room, bearing should be carefully selected, bearing with baffle passes through grinding, and in keeping the baffle on inner and outer contour under the premise of baffle parallelism should be controlled below 1 um.
2. Bearing should be cleaned before installed and when cleaning inner ring ramp up, flexible hand induction, no stagnation, air-dried, into the specified amount oil, if oil mist lubrication oil should be in a small amount of oil mist;
3. The bearing installation should use specialized tools, force uniform, do not knock;
4. Bearing deposit should be clean and ventilated, non-corrosive gas, relative humidity is not more than 65%, long-term storage should be rust on a regular basis.



3 . Types :



Single row angular contact ball bearings
Single row angular contact ball bearings can only carry axial load in one direction, when bear radial load, will cause the additional axial force, must be applied to the corresponding reverse load, therefore, this kind of bearings are generally used in pairs.Double row angular contact ball bearings can withstand the bigger radial direction load primarily radial, axial two-way joint load and torque load, it can limit shaft or shell two-way axial displacement, the contact Angle of 30 degrees





4 . Competitive Advantage:


· Competitive Price
· Big Production Ability
· Fast Delivery
· Excellent Sale and After-sale Service
· OEM Available



5. APPLICATION:

Papermaking machinery, reducer, railway vehicle axle, gear box bearing, rolling mill rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industrial reducer, Papermaking machinery, deceleration devices, railway vehicle axles, gear box bearing rolling mill, rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industrial gear, vertical seat belt aligning bearings


6 . We have enough stock , following is our products in stock .


Principal dimensions Basic load ratings Reference speed Limiting speed Model no.
dynamic static
d D B C C0
mm kN   r/min
65 140 33 116 86,5 6300 6300 7313 BECBP *
65 140 33 116 86,5 6300 6300 7313 BEGAP *
65 140 33 116 86,5 6300 6300 7313 BEGBP *
65 140 33 116 86,5 6300 6300 7313 BECBPH *
65 140 33 116 86,5 6300 6300 7313 BECBM *
65 140 33 116 86,5 6300 6300 7313 BECCM *
65 140 33 116 86,5 6300 6300 7313 BEGAM *
65 140 33 116 86,5 6300 6300 7313 BEGBM *
65 160 37 130 96,5 5000 5300 7413 BCBM
65 160 37 130 96,5 5000 5300 7413 BGAM
65 160 37 130 96,5 5000 5300 7413 BGBM
70 125 24 67,6 56 6000 6000 7214 BEP
70 125 24 71,5 60 6000 6000 7214 BECBJ
70 125 24 71,5 60 6000 6000 7214 BECBY
70 125 24 72 60 6300 6300 7214 BECBP *
70 125 24 75 64 6300 6300 7214 BEGAP *
70 125 24 72 60 6300 6300 7214 BECBM *
70 125 24 72 60 6300 6300 7214 BEGAM *
70 150 35 119 90 5300 5300 7314 BEP
70 150 35 119 90 5300 5300 7314 BECBJ
70 150 35 119 90 5300 5300 7314 BEGAJ
70 150 35 119 90 5300 5300 7314 BECBY
70 150 35 119 90 5300 5300 7314 BEGAY
70 150 35 119 90 5300 5300 7314 BEGBY
70 150 35 119 90 5300 5300 7314 BEGAF
70 150 35 127 98 5600 5600 7314 BECBP *
70 150 35 127 98 5600 5600 7314 BECAP *
70 150 35 127 98 5600 5600 7314 BEGAP *
70 150 35 127 98 5600 5600 7314 BECBPH *
70 150 35 127 98 5600 5600 7314 BECBM *
70 150 35 127 98 5600 5600 7314 BEGAM *
70 180 42 159 127 4500 4800 7414 BCBM
70 180 42 159 127 4500 4800 7414 BGAM
75 130 25 70,2 60 5600 5600 7215 BEP
75 130 25 73,5 65,5 6300 6300 7215 BECBP
75 130 25 73,5 65,5 6300 6300 7215 BECBM
75 130 25 72,8 64 5600 5600 7215 BECBJ
75 130 25 72,8 64 5600 5600 7215 BECBY
75 130 25 72,8 64 5600 5600 7215 BEGAY
75 160 37 125 98 5000 5000 7315 BEP
75 160 37 133 106 5000 5000 7315 BECBJ
75 160 37 133 106 5000 5000 7315 BECBY
75 160 37 132 104 5300 5300 7315 BECBP *
75 160 37 132 104 5300 5300 7315 BEGAP *
75 160 37 132 104 5300 5300 7315 BECBPH *
75 160 37 132 104 5300 5300 7315 BECBM *
75 160 37 132 104 5300 5300 7315 BEGAM *
75 190 45 168 140 4300 4500 7415 BM
75 190 45 168 140 4300 4500 7415 BCBM
75 190 45 168 140 4300 4500 7415 BGAM
75 190 45 168 140 4300 4500 7415 BGBM
80 140 26 80,6 69,5 5300 5300 7216 BEP
80 140 26 83,2 73,5 5300 5300 7216 BECBJ
80 140 26 83,2 73,5 5300 5300 7216 BECBY
80 140 26 80,6 69,5 5300 5300 7216 BEGAF
80 140 26 85 75 5600 5600 7216 BECBP *



Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2 0

Size 75*190*45 Angular Contact Ball Bearing 7415 BCBM P0 P6 P5 P4 P2 1
